Swivel Hoist Ring – Long with Long Screw

Price range: $86.59 through $346.75

Heavy-duty Bent Lashing Ring forged from 316 stainless steel for superior corrosion resistance. Designed for demanding tie-down applications, it features a weld-on mounting plate and a bent “D” ring for easy, one-handed attachment—perfect for cargo, container shipments, and long-distance hauling.

SKU: S37226756f506a6f74-1 Category:
[porto_single_product_wishlist show_label=”yes” el_class=”d-inline-block align-middle mt-2 pt-1″ label_font=”{“family“:“Default“,“variant“:“700“,“font_size“:“13“,“line_height“:““,“letter_spacing“:““,“text_transform“:“uppercase“}” icon_added_color=”var(–porto-primary-color)” label_color=”#222529″ bg_hover_color=”#ffffff” label_hover_color=”var(–porto-primary-color)”]

Description

The Stainless Swivel Hoist Ring – Long with Long Screw delivers safe overhead lifting. Forged 316 stainless steel resists saltwater and harsh weather. It swivels 360° and pivots 180° to follow the load.

The long bail fits larger shackles and hooks. Each part has a 5:1 safety factor and engraved WLL and torque values. Torque the screw before each lift.

Additional information

Weight N/A
ITEM

S0325-1333L, S0325-1638L, S0325-2045L, S0325-2250L

A (UNC thread)

1/2-13, 5/8-11, 3/4-10, 7/8-9

B

1.29″, 1.47″, 1.80″, 1.96″

C

1.07″, 1.26″, 1.52″, 1.73″

D

0.63″, 0.75″, 0.88″, 1.00″

E

4.00″, 4.33″, 4.48″, 4.44″

F

1.81″, 2.06″, 2.44″, 2.81″

X

3.65″, 4.20″, 4.91″, 5.64″

Y

6.90″, 7.68″, 8.61″, 9.13″

Z

1.75″, 2.00″, 2.38″, 2.75″

WLL (lb)

1,600, 2,200, 3,200, 4,400

WT (lb)

3.10, 4.70, 7.60, 10.90
