Swivel Hoist Ring – Long with Long Screw
Price range: $86.59 through $346.75
Heavy-duty Bent Lashing Ring forged from 316 stainless steel for superior corrosion resistance. Designed for demanding tie-down applications, it features a weld-on mounting plate and a bent “D” ring for easy, one-handed attachment—perfect for cargo, container shipments, and long-distance hauling.
- Description
- Additional information
Description
The Stainless Swivel Hoist Ring – Long with Long Screw delivers safe overhead lifting. Forged 316 stainless steel resists saltwater and harsh weather. It swivels 360° and pivots 180° to follow the load.
The long bail fits larger shackles and hooks. Each part has a 5:1 safety factor and engraved WLL and torque values. Torque the screw before each lift.
Additional information
| Weight | N/A |
|---|---|
| ITEM | S0325-1333L, S0325-1638L, S0325-2045L, S0325-2250L |
| A (UNC thread) | 1/2-13, 5/8-11, 3/4-10, 7/8-9 |
| B | 1.29″, 1.47″, 1.80″, 1.96″ |
| C | 1.07″, 1.26″, 1.52″, 1.73″ |
| D | 0.63″, 0.75″, 0.88″, 1.00″ |
| E | 4.00″, 4.33″, 4.48″, 4.44″ |
| F | 1.81″, 2.06″, 2.44″, 2.81″ |
| X | 3.65″, 4.20″, 4.91″, 5.64″ |
| Y | 6.90″, 7.68″, 8.61″, 9.13″ |
| Z | 1.75″, 2.00″, 2.38″, 2.75″ |
| WLL (lb) | 1,600, 2,200, 3,200, 4,400 |
| WT (lb) | 3.10, 4.70, 7.60, 10.90 |
